Firefly® LED Cable Protector Specifications | General: | Model No. | FCP-232 | FCP-232-BLU | FCP-332 | FCP-332-BLU | FCP-532 | FCP-532-BLU | FDO-132FDO-132-BLUFDO-132-BLK | FDO-232FDO-232-BLUFDO-232-BLK | Series | EventSeries™ | EventSeries™ | SatelliteSeries™ | SatelliteSeries™ | EnergySeries™ | EnergySeries™ | FacilitySeries™ | IndustrialSeries™ | Channels | 2 | 2 | 3 | 3 | 5 | 5 | 1 | 2 | Capacity | Heavy
Duty | Heavy Duty | Heavy Duty | Heavy Duty | Heavy
Duty | Heavy Duty | Medium Duty | Medium Duty | Color-Ramp | Black | Black | Black | Black | Black | Black | Safety
Green,Safety Blue,or Black | Safety Green,Safety Blue,or Black | Color-Lid/Cover | Safety
Green | Safety Blue | Safety Green | Safety Blue | Safety
Green | Safety Blue | n/a | n/a | Patent
No. | 6,499,410 | 6,499,410 | 6,499,410 | 6,499,410 | 6,499,410 | 6,499,410 | 6,499,410 | 6,499,410 | Weight: | Weight
(lbs.) | 17.00 | 17.00 | 22.00 | 22.00
| 25.00 | 25.00 | Weight (kg) | 7.71 | 7.71
| 9.98 | 9.98 | 11.34 | 11.34 | Linear Dimensions: | Length-Overall (in) | 36.00
| 36.00 | 36.00 | 36.00 | 36.00
| 36.00 | Length-Overall (cm) | 91.44 | 91.44 | 91.44 | 91.44 | 91.44 | 91.44 | Length-Ramp
(in) | 32.00 | 32.00 | 32.00 | 32.00
| 32.00 | 32.00 | Length-Ramp (cm) | 81.28 | 81.28
| 81.28 | 81.28 | 81.28 | 81.28 | Width-Overall (in) | 14.63
| 14.63 | 16.50 | 16.50 | 20.25
| 20.25 | Width-Overall (cm) | 37.16 | 37.16 | 40.64 | 40.64 | 50.17 | 50.17 | Width-Lid/Top
(in) | 4.75 | 4.75 | 6.60 | 6.60
| 10.50 | 10.50 | Width-Lid/Top (cm) | 12.07 | 12.07
| 17.00 | 17.00 | 26.70 | 26.70 | Height (in) | 1.91
| 1.91 | 1.91 | 1.91 | 1.91
| 1.91 | Height (cm) | 4.85 | 4.85 | 4.85 | 4.85 | 4.85 | 4.85 | Channel Dimensions: | Width-Channels
(in) | 1.35 | 1.35 | 1.35 | 1.35
| 1.35 | 1.35 | Width-Channels (cm) | 3.43 | 3.43
| 3.43 | 3.43 | 3.43 | 3.43 | Width-Center Channel (in) | n/a | n/a | 1.35
| 1.35 | 1.67 | 1.67 | Width-Center Channel (cm) | n/a | n/a | 3.43 | 3.43 | 4.24 | 4.24 | Height-Channels (in) | 1.15 | 1.15
| 1.15 | 1.15 | 1.15 | 1.15
| Height-Channels (cm) | 2.92
| 2.92 | 2.92 | 2.92 | 2.92 | 2.92 | Slope Angles: | Ramp
(degrees) | 16 | 16 | 16 | 16
| 16 | 16 | Lid
Opening (degrees) | 100 | 100 | 100 | 100
| 100 | 100 | Material Specifications: | Material | CastPolyurethane | CastPolyurethane | CastPolyurethane | CastPolyurethane | CastPolyurethane | CastPolyurethane | Stability | UV
Stablized | UV Stablized | UV Stablized | UV Stablized | UV
Stablized | UV Stablized | Chemical Resistance | Good | Good | Good | Good | Good | Good | Operating
Temp (F) | -30 to 140 | -30 to 141 | -30
to 142 | -30 to 143 | -30 to 144 | -30
to 145 | Operating Temp (C) | -34 to 60 | -34 to 61 | -34 to 62 | -34
to 63 | -34 to 64 | -34 to 65 | Max.
Load Capacity (lbs.)per axle @ 70 degrees (F) | 24,000 | 24,000 | 24,000
| 24,000 | 24,000 | 24,000 | Max. Load Capacity (kg)per axle @ 21 degrees (C) | 10,866 | 10,866 | 10,866 | 10,866
| 10,866 | 10,866 | Hinge
Pin | ReinforcedFiberglass | ReinforcedFiberglass | ReinforcedFiberglass | ReinforcedFiberglass | ReinforcedFiberglass | ReinforcedFiberglass | Corner
Inserts | StainlessSteel | StainlessSteel | StainlessSteel | StainlessSteel | StainlessSteel | StainlessSteel | Connector
Style | BootConnector™ | BootConnector™ | BootConnector™ | BootConnector™ | BootConnector™ | BootConnector™ | Waterproof Electronics Specifications: | Warning
Lights | Red LED | Blue LED | Red LED | Blue
LED | Red LED | Blue LED | Warning
Type | AnimatedLED Strip X 2 | AnimatedLED Strip X 2 | AnimatedLED
Strip X 2 | AnimatedLED Strip X 2 | AnimatedLED Strip X 2 | AnimatedLED
Strip X 2 | LED Strip | Sealed in ClearPolyurethane | Sealed
in ClearPolyurethane | Sealed in ClearPolyurethane | Sealed in ClearPolyurethane | Sealed
in ClearPolyurethane | Sealed in ClearPolyurethane | Operating
Temp (F) | 14 to 149 | 14 to 149 | 14 to 149 | 14
to 149 | 14 to 149 | 14 to 149 | Operating Temp (C) | -10 to 65 | -10
to 65 | -10 to 65 | -10 to 65 | -10 to 65 | -10 to 65 | Suggested
Battery Type | 2 AA 1.5V DuracellMN1500 | 2 AA 1.5V DuracellMN1500 | 2
AA 1.5V DuracellMN1500 | 2 AA 1.5V DuracellMN1500 | 2 AA 1.5V DuracellMN1500 | 2
AA 1.5V DuracellMN1500 | Battery Op. Temp. (F) | -4 to 129 | -4
to 129 | -4 to 129 | -4 to 129 | -4 to 129 | -4
to 129 | Battery Op. Temp. (C) | -20
to 54 | -20 to 54 | -20 to 54 | -20 to 54 | -20 to 54 | -20
to 54 | Battery Life (Approx.) | 500 hours | 500 hours | 500
hours | 500 hours | 500 hours | 500 hours | On/Off
Switch | Push Buttonw/ Red Boot | Push Buttonw/ Red Boot | Push
Buttonw/ Red Boot | Push Buttonw/ Red Boot | Push Buttonw/ Red
Boot | Push Buttonw/ Red Boot | Battery Box Seal | #151
"O" Ring | #151 "O" Ring | #151 "O"
Ring | #151 "O" Ring | #151 "O" Ring | #151
"O" Ring | Note: All specification are subject to change without notice. |
|
